SKF

SKF 6316 M/C3 single-row groove ball bearing cylindrical 80x170x39 mm

Recommended Retail Price €1,050.29
519.95 tax incl.
€429.71 excl. VAT (incl. all environmental contributions)
On order: delivered from 23/05/2026
each

  • Delivery by DHL

Product description

Single row deep groove ball bearings are particularly versatile, have low friction and are optimized for low noise and low vibration, which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount, and require less maintenance than many other bearing types.

  • Simple, versatile and robust design
  • Low friction
  • High-speed capability
  • Accommodate radial and axial loads in both directions
  • Require little maintenance
Key features according to our expert
  • Inner diameter: 80 mm
  • Width: 39 mm
  • Number of rows: 1
  • Seal (bearing): Without seal
  • Material (bearing seal): Not applicable
  • Radial clearance: C3
  • Material (bearing): Steel
  • Material (cage): Brass (solid)
  • Bore type: Cylindrical
  • High temperature: No
  • Outer diameter: 170 mm
Specifications / All features
  • Brand: SKF
  • EAN: 7316571154756
  • Supplier number: SKF 6316 M/C3
Inner diameter
80 mm
Width
39 mm
Number of rows
1
Seal (bearing)
Without seal
Material (bearing seal)
Not applicable
Radial clearance
C3
Material (bearing)
Steel
Material (cage)
Brass (solid)
Bore type
Cylindrical
High temperature
No
Outer diameter
170 mm
Matched arrangement
No
Tolerance class
Normal
Radial internal clearance
C3
Basic static load rating
86.5
Material, bearing
Bearing steel
Relubrication feature
Without
Reference speed
8500
Skf performance class
SKF Explorer
Lubricant
None
Cage
Machined metal
Locating feature, bearing outer ring
None
Filling slots
Without
Coating
Without
Sealing
Without
Limiting speed
7500
Bore diameter
80
Basic dynamic load rating
130
Outside diameter
170
