What are the dimensions of this SKF ball bearing?

The bearing has an inside diameter of 8 mm, an outside diameter of 16 mm, and a width of 5 mm.

What sealing does the 628/8-2RS1 bearing have?

It features rubber contact seals on both sides (2RS1) to keep out dirt and moisture.

What internal radial clearance does this bearing have?

This model has normal radial internal clearance (class CN).

What type of bore does this deep groove ball bearing have?

It has a standard cylindrical bore designed for mounting on a straight 8 mm shaft.

Is this SKF bearing suitable for high-temperature use?

No, this standard steel bearing is not designed for dedicated high-temperature applications.

SKF 628/8-2RS1 single-row groove ball bearing cylindrical 8x16x5 mm

Supplier number: SKF 628/8-2RS1 | EAN 7316570976151

Recommended Retail Price €30.43

14.95 tax incl.

€12.35 excl. VAT (incl. all environmental contributions)

On stock - immediately available

Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Smooth rotation with the Skf deep groove ball bearing

Practical benefits

Reliable protection against contaminants: Thanks to rubber contact seals on both sides, you keep lubricant inside and block dirt or moisture.
Smooth high speed operation: The low friction design ensures quiet running and minimal heat build-up across demanding, compact mechanical applications.
Versatile bidirectional load support: You can easily support steady radial loads as well as light axial forces acting in both directions.

In a nutshell

The right choise for

With the Skf 628/8-2RS1 deep groove ball bearing, you ensure smooth, low-friction rotation in compact machinery and assemblies. Thanks to rubber contact seals on both sides, factory lubricant stays inside while dust, dirt, and moisture are reliably kept out. Featuring a cylindrical 8 mm bore, a 16 mm outside diameter, and a 5 mm width, this single row steel bearing is well suited for high-speed operation. It easily supports steady radial loads as well as light bidirectional axial forces, making it an ideal choice for small electric motors, robotics, and precision mechanical drives.

Product information FAQ

€14.95

In stock - tax incl.

Key features according to our expert

Inner diameter: 8 mm
Width: 5 mm
Number of rows: 1
Sealing (bearing): Sealed on both sides
Material (bearing seal): Rubber
Radial clearance: CN (Normal)
Material (bearing): Steel
Material (cage): Brass (sheet)
Bore type: Cylindrical
High temperature: No
Outer diameter: 16 mm

Product description

Single row deep groove ball bearings with seals or shields are particularly versatile, have low friction and are optimized for low noise and low vibration, which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount, and require less maintenance than many other bearing types. The integral sealing can significantly prolong bearing service life because it keeps lubricant in the bearings and contaminants out.

Integral sealing prolongs bearing service life
Simple, versatile and robust design
Low friction and high-speed capability
Accommodate radial and axial loads in both directions
Require little maintenance

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 8 mm
Width: 5 mm
Number of rows: 1
Sealing (bearing): Sealed on both sides
Material (bearing seal): Rubber
Radial clearance: CN (Normal)
Material (bearing): Steel
Material (cage): Brass (sheet)
Bore type: Cylindrical
High temperature: No
Outer diameter: 16 mm
Matched arrangement: No
Tolerance class: Class P6 (P6)
Radial internal clearance: CN
Basic static load rating: 0.57
Material, bearing: Bearing steel
Relubrication feature: Without
Lubricant: Grease
Sealing type: Contact
Cage: Sheet metal
Locating feature, bearing outer ring: None
Filling slots: Without
Coating: Without
Sealing: Seal on both sides
Limiting speed: 26000
Bore diameter: 8
Basic dynamic load rating: 1.33
Outer diameter: 16

Brand SKF
01011468
EAN 7316570976151
Supplier number SKF 628/8-2RS1

Frequently asked questions about this product

Answered by specialists

What are the dimensions of this SKF ball bearing?: The bearing has an inside diameter of 8 mm, an outside diameter of 16 mm, and a width of 5 mm.
What sealing does the 628/8-2RS1 bearing have?: It features rubber contact seals on both sides (2RS1) to keep out dirt and moisture.
What internal radial clearance does this bearing have?: This model has normal radial internal clearance (class CN).
What type of bore does this deep groove ball bearing have?: It has a standard cylindrical bore designed for mounting on a straight 8 mm shaft.
Is this SKF bearing suitable for high-temperature use?: No, this standard steel bearing is not designed for dedicated high-temperature applications.
