Product description: Deep groove ball bearings are particularly versatile They are simple in design, not removable, suitable for high to very high speeds and are very robust in operation, requiring little maintenance Deep raceways and close contact between raceways and balls make deep groove ball bearings suitable not only for radial loads, but also for axial loads in both directions, even at high speeds
Key features according to our expert
Inner diameter: 70 mm
Width: 24 mm
Number of rows: 1
Seal (bearing): Without seal
Material (bearing seal): Not applicable
Radial clearance: C4
Material (bearing): Steel
Material (cage): Brass (solid)
Bore type: Cylindrical
High temperature: No
Outer diameter: 125 mm
Specifications / All features
Brand:
SKF
01014493
EAN:
7316571142234
Supplier number:
SKF 6214 M/C4VL0241
Inner diameter
70 mm
Width
24 mm
Number of rows
1
Seal (bearing)
Without seal
Material (bearing seal)
Not applicable
Radial clearance
C4
Material (bearing)
Steel
Material (cage)
Brass (solid)
Bore type
Cylindrical
High temperature
No
Outer diameter
125 mm
Matched arrangement
No
Tolerance class
Normal
Radial internal clearance
C4
Basic static load rating
45 kN
Material, bearing
Bearing steel
Relubrication feature
Without
Reference speed
11,000 r/min
Lubricant
None
Cage
Machined metal
Locating feature, bearing outer ring
None
Filling slots
Without
Coating
Insulation coating on outer ring
Sealing
Without
Limiting speed
10,000 r/min
Bore diameter
70 mm
Basic dynamic load rating
63.7 kN
Outside diameter
125 mm
