What are the dimensions of this deep groove ball bearing?

The bearing has an inside diameter of 35 mm, an outside diameter of 47 mm, and a width of 7 mm.

What does the 2RS1 designation mean?

It indicates that the bearing is fitted with rubber contact seals on both sides to keep out dust and moisture.

What types of loads can this ball bearing handle?

This single-row deep groove ball bearing accommodates radial loads as well as axial loads in both directions.

What is the radial internal clearance of this bearing?

This model features standard normal radial internal clearance (designated as CN).

Does this bearing require lubrication before installation?

No, the bearing comes pre-lubricated with grease from the factory and is maintenance-free.

SKF 61807-2RS1 single-row groove ball bearing cylindrical 35x47x7 mm

Supplier number: SKF 61807-2RS1 | EAN 7316577308832

Recommended Retail Price €94.97

46.95 tax incl.

€38.80 excl. VAT (incl. all environmental contributions)

On stock - immediately available | we have 3 products in stock.

Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Smooth rotation with Skf

Practical benefits

Reliable sealing against contaminants: With rubber contact seals on both sides, you keep dirt and moisture away from the internal raceways.
Space-saving slim profile design: Measuring 35X47X7 mm, this thin-section bearing allows you to fit smooth rotational performance into tight machine housings.
Robust and durable steel: The high-grade bearing steel construction lets you carry radial and moderate axial loads with low friction.

In a nutshell

The right choise for

Ensure smooth and reliable rotation in compact assemblies with the Skf 61807-2RS1 single-row deep groove ball bearing. With its slim 35X47X7 mm profile, this steel bearing easily fits into tight spaces such as bicycle bottom brackets, electric motors, and precision drives. The double-sided rubber contact seals keep dust, dirt, and moisture out while retaining factory lubrication for dependable, maintenance-free performance. Featuring standard cn radial internal clearance, it accommodates radial and axial loads in both directions, giving you the durability and low friction needed for demanding mechanical applications.

Product information FAQ

€46.95

In stock - tax incl.

Key features according to our expert

Inner diameter: 35 mm
Width: 7 mm
Number of rows: 1
Sealing (bearing): Sealed on both sides
Material (bearing seal): Rubber
Radial clearance: CN (Normal)
Material (bearing): Steel
Material (cage): Brass (sheet)
Bore type: Cylindrical
High temperature: No
Outer diameter: 47 mm

Product description

Single row deep groove ball bearings with seals or shields are particularly versatile, have low friction and are optimized for low noise and low vibration, which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount, and require less maintenance than many other bearing types. The integral sealing can significantly prolong bearing service life because it keeps lubricant in the bearings and contaminants out.

Integral sealing prolongs bearing service life
Simple, versatile and robust design
Low friction and high-speed capability
Accommodate radial and axial loads in both directions
Require little maintenance

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 35 mm
Width: 7 mm
Number of rows: 1
Sealing (bearing): Sealed on both sides
Material (bearing seal): Rubber
Radial clearance: CN (Normal)
Material (bearing): Steel
Material (cage): Brass (sheet)
Bore type: Cylindrical
High temperature: No
Outer diameter: 47 mm
Matched arrangement: No
Tolerance class: Normal
Radial internal clearance: CN
Basic static load rating: 3.2
Material, bearing: Bearing steel
Relubrication feature: Without
Lubricant: Grease
Sealing type: Contact
Cage: Sheet metal
Locating feature, bearing outer ring: None
Filling slots: Without
Coating: Without
Sealing: Seal on both sides
Limiting speed: 15000
Bore diameter: 35
Basic dynamic load rating: 4.75
Outer diameter: 47

Brand SKF
01011278
EAN 7316577308832
Supplier number SKF 61807-2RS1

Frequently asked questions about this product

Answered by specialists

What are the dimensions of this deep groove ball bearing?: The bearing has an inside diameter of 35 mm, an outside diameter of 47 mm, and a width of 7 mm.
What does the 2RS1 designation mean?: It indicates that the bearing is fitted with rubber contact seals on both sides to keep out dust and moisture.
What types of loads can this ball bearing handle?: This single-row deep groove ball bearing accommodates radial loads as well as axial loads in both directions.
What is the radial internal clearance of this bearing?: This model features standard normal radial internal clearance (designated as CN).
Does this bearing require lubrication before installation?: No, the bearing comes pre-lubricated with grease from the factory and is maintenance-free.
