What are the dimensions of this deep groove ball bearing?

The bearing has an inside diameter of 7 mm, an outside diameter of 19 mm, and a width of 6 mm.

What does the 2Z designation mean?

The 2Z suffix indicates that the bearing has metal shields on both sides to keep contaminants out.

What does the C3 radial clearance mean on this SKF bearing?

C3 indicates an internal radial clearance greater than normal, ideal for higher rotational speeds or thermal expansion.

What type of bore does this SKF 607-2Z/C3 have?

This ball bearing features a cylindrical bore.

Is this SKF ball bearing suitable for high-temperature applications?

No, this specific variant is not rated for high-temperature environments.

SKF 607-2Z/C3 single-row groove ball bearing cylindrical 7x19x6 mm

Supplier number: SKF 607-2Z/C3 | EAN 7316570660951

9.44 tax incl.

€7.80 excl. VAT (incl. all environmental contributions)

On stock - immediately available

Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Dependable performance with Skf engineering

Practical benefits

Shielded against external debris: Dual steel shields retain internal lubrication while preventing dust and debris from entering the bearing.
Optimized for higher speeds: The C3 internal clearance reduces friction and operating temperature, ensuring smooth high-speed rotation.
Low-maintenance and durable design: Premium steel construction accommodates both radial and light axial loads with minimal routine maintenance required.

In a nutshell

The right choise for

Keep your equipment running smoothly and reliably with the Skf 607-2Z/C3 deep groove ball bearing. Featuring a 7 mm bore, 19 mm outer diameter, and 6 mm width, this compact steel bearing is built for demanding setups such as small electric motors, power tools, and precision machinery. The increased C3 internal clearance accommodates thermal expansion and high rotational speeds without seizing. Equipped with dual metal shields, it retains internal lubrication while shielding against external dust and debris. This robust single-row design handles radial and light axial loads with ease, ensuring durable, low-maintenance performance on every job.

Product information FAQ

€9.44

In stock - tax incl.

Key features according to our expert

Inner diameter: 7 mm
Width: 6 mm
Number of rows: 1
Sealing (bearing): Sealed on both sides
Material (bearing seal): Metal
Radial clearance: C3
Material (bearing): Steel
Material (cage): Brass (sheet)
Bore type: Cylindrical
High temperature: No
Outer diameter: 19 mm

Product description

Single row deep groove ball bearings with seals or shields are particularly versatile, have low friction and are optimized for low noise and low vibration, which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount, and require less maintenance than many other bearing types. The integral sealing can significantly prolong bearing service life because it keeps lubricant in the bearings and contaminants out.

Integral sealing prolongs bearing service life
Simple, versatile and robust design
Low friction and high-speed capability
Accommodate radial and axial loads in both directions
Require little maintenance

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 7 mm
Width: 6 mm
Number of rows: 1
Sealing (bearing): Sealed on both sides
Material (bearing seal): Metal
Radial clearance: C3
Material (bearing): Steel
Material (cage): Brass (sheet)
Bore type: Cylindrical
High temperature: No
Outer diameter: 19 mm
Relubrication feature: Without
Radial internal clearance: C3
Basic static load rating: 0.95
Matched arrangement: No
Material, bearing: Bearing steel
Reference speed: 85000
Skf performance class: SKF Explorer
Lubricant: Grease
Sealing type: Non-contact
Cage: Sheet metal
Filling slots: Without
Tolerance class: Class P6 (P6)
Basic dynamic load rating: 2.34
Locating feature, bearing outer ring: None
Sealing: Shield on both sides
Limiting speed: 43000
Bore diameter: 7
Coating: Without
Outer diameter: 19

Brand SKF
01011250
EAN 7316570660951
Supplier number SKF 607-2Z/C3

Frequently asked questions about this product

Answered by specialists

What are the dimensions of this deep groove ball bearing?: The bearing has an inside diameter of 7 mm, an outside diameter of 19 mm, and a width of 6 mm.
What does the 2Z designation mean?: The 2Z suffix indicates that the bearing has metal shields on both sides to keep contaminants out.
What does the C3 radial clearance mean on this SKF bearing?: C3 indicates an internal radial clearance greater than normal, ideal for higher rotational speeds or thermal expansion.
What type of bore does this SKF 607-2Z/C3 have?: This ball bearing features a cylindrical bore.
Is this SKF ball bearing suitable for high-temperature applications?: No, this specific variant is not rated for high-temperature environments.
