Which shaft diameter is this insert bearing suitable for?

This bearing is designed for a metric shaft with a diameter of 30 mm.

How is the bearing mounted on the shaft?

You lock the extended inner ring onto the shaft by tightening the two integrated set screws.

What are the dimensions of the SKF YAR 206-2RF?

The bearing has an inside diameter of 30 mm, an outside diameter of 62 mm, and a total width of 38,1 mm.

Can this bearing handle alternating rotation directions?

Yes, the set screw locking mechanism makes it suitable for both constant and alternating directions of rotation.

What materials are used in this bearing?

The bearing is made of steel and is equipped with a non-metallic polymer cage.

SKF YAR 206-2RF Y insert bearing cylindrical with set screw for metric shaft, 30 x 62 mm

Supplier number: SKF YAR 206-2RF | EAN 7316570176469

Recommended Retail Price €81.18

39.95 tax incl.

€33.02 excl. VAT (incl. all environmental contributions)

On stock - immediately available

Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Smooth shaft rotation with Skf

Practical benefits

Quick and secure mounting: You clamp the extended inner ring securely onto the shaft using two set screws.
Suitable for alternating rotations: Designed to support constant and alternating rotational directions while reducing vibration and noise.
Reliable protection against contaminants: Built-in contact seals keep lubricant in place and keep dust away from internal components.

In a nutshell

The right choise for

With the Skf yar 206-2RF insert bearing, you achieve stable and reliable shaft support in conveyor systems and machinery. Thanks to the inner ring extended on both sides, you easily mount the bearing onto a 30 mm shaft and lock it firmly in place using two integrated set screws. This minimizes tilting and makes the bearing fully suitable for both constant and alternating rotation directions. Its durable steel build with a polymer cage and built-in contact seals keeps contaminants out, ensuring smooth operation and long service life.

Product information FAQ

€39.95

In stock - tax incl.

Key features according to our expert

Inner diameter: 30 mm
Width: 38,1 mm
Material (bearing): Steel
Material (cage): Plastic
High temperature: No
Bore type: Cylindrical
Inner ring extension: On both sides
Outer diameter: 62 mm

Product description

Insert bearings are based on sealed deep groove ball bearings. This variant is suitable for applications with both constant and alternating directions of rotation. It has an inner ring extended on both sides and is locked onto the shaft by tightening two (set) screws on the inner ring, making it easy to mount.

Designed for a constant and alternating rotation
Quick and easy to mount onto the shaft
Reduce noise and vibration levels

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 30 mm
Width: 38,1 mm
Material (bearing): Steel
Material (cage): Plastic
High temperature: No
Bore type: Cylindrical
Inner ring extension: On both sides
Outer diameter: 62 mm
Width, outer ring: 18
Basic static load rating: 11.2
Relubrication feature: With
Lubricant: Grease
Rubber seating ring: Without
Sealing type: Contact, multiple
Cage: Non-metallic
Material, bearing: Bearing steel
Sealing: Seal and flinger on both sides
Rolling elements: Balls
Application: For material handling applications
Retaining feature, inner ring: Set screws
Limiting speed: 3800
Outer ring type: Spherical
Width, total: 38.1
Width, inner ring: 38.1
Shaft diameter: 30
Bore diameter: 30
Basic dynamic load rating: 19.5
Coating: Without
Outer diameter: 62
Note: Limiting speed with shaft tolerance h6

Brand SKF
01190657
EAN 7316570176469
Supplier number SKF YAR 206-2RF

Frequently asked questions about this product

Answered by specialists

Which shaft diameter is this insert bearing suitable for?: This bearing is designed for a metric shaft with a diameter of 30 mm.
How is the bearing mounted on the shaft?: You lock the extended inner ring onto the shaft by tightening the two integrated set screws.
What are the dimensions of the SKF YAR 206-2RF?: The bearing has an inside diameter of 30 mm, an outside diameter of 62 mm, and a total width of 38,1 mm.
Can this bearing handle alternating rotation directions?: Yes, the set screw locking mechanism makes it suitable for both constant and alternating directions of rotation.
What materials are used in this bearing?: The bearing is made of steel and is equipped with a non-metallic polymer cage.
