SKF SILKAC 5 M Rod head with female thread, left-hand thread 5 mm, M 5

SKF
Supplier number: SKF SILKAC 5 M | EAN 7316577104274
Recommended Retail Price €133.00
65.80 tax incl.
€54.38 excl. VAT (incl. all environmental contributions)
On order: delivered from 20/10/2026

  • Delivery by DHL
↓ Documents (1) ✆ Talk to a specialist


Product information
€65.80
tax incl.

Product information

Key features according to our expert

  • Inner diameter: 5 mm
  • Connection type: Internal thread
  • Thread type: Metric - Left
  • Sealing (bearing): Without seals
  • Maintenance free: Nein
  • Connection size: M5

Product description

These SKF rod ends contain a spherical plain bearing with a steel/bronze sliding contact surface combination. The bearing requires maintenance, sizes 6 and larger can be relubricated via a grease fitting in the housing and via the shank. The female thread is available with a left- (prefix SIL) or right-hand thread.

  • Suitable where lubricant starvation might occur
  • Simple and ready-to-mount
  • Easy to relubricate (sizes >= 6)

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter
5 mm
Connection type
Internal thread
Thread type
Metric - Left
Sealing (bearing)
Without seals
Maintenance free
Nein
Connection size
M5
Basic static load rating
5.4
Attachment feature, rod end shank
Left-hand female thread
Material, housing
Steel
Sliding contact surface combination
Steel/bronze
Housing length, total
37
Maintenance
Relubrication required
Thread designation
M 5
Outside diameter, housing eye
19
Bore diameter, bearing inner ring
5
Sealing
Without
Material, inner ring
Bearing steel
Width, bearing inner ring
8
Width, housing eye
7.5
Basic dynamic load rating
3.25
Centre height, housing (from end of shank)
27
  • Brand SKF
  • EAN 7316577104274
  • Supplier number SKF SILKAC 5 M
