What thread type does this SKF rod end have?

It features a metric fine female thread sized at M20x1.5 (right-hand thread).

What is the bore diameter of the bearing?

The bore inner diameter of the bearing is 20 mm.

Does the SKF SIKB 20 F require regular lubrication?

No, this rod end is maintenance-free due to its PTFE FRP sliding contact surface and requires no relubrication.

Does this rod end include seals?

No, this standard model is designed without integrated seals.

What applications is the SKF SIKB 20 F designed for?

It is designed for linkage assemblies and mechanical connections handling heavy loads and oscillating movements.

SKF SIKB 20 F Rod head with female thread 20 mm, M 20x1.5

Supplier number: SKF SIKB 20 F | EAN 7316577003874

Recommended Retail Price €382.65

189.40 tax incl.

€156.53 excl. VAT (incl. all environmental contributions)

On stock - immediately available | we have 2 products in stock.

Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Reliable linkage motion for machinery components

Practical benefits

Completely maintenance-free operation: The integrated PTFE sliding layer ensures you never need relubrication, cutting downtime and servicing effort significantly.
Accurate mechanical fit: With its precise M20 x 1.5 female thread and 20 mm bore, you achieve a direct, secure linkage connection.
Dependable Skf rod end: You easily accommodate angular misalignments and oscillating movements while maintaining smooth, durable mechanical performance.

In a nutshell

The right choise for

With the Skf sikb 20 f rod end, you create a dependable and durable connection in mechanical linkages and industrial machinery. Thanks to the self-lubricating ptfe frp sliding layer, this rod end is completely maintenance-free, eliminating the need for periodic relubrication and minimizing downtime. Featuring a precise 20 mm bore and a right-hand M20 x 1.5 female thread, it attaches accurately and securely to compatible rods and cylinders. It effortlessly accommodates angular misalignments and oscillating movements under heavy loads, ensuring smooth and reliable machine operation.

Product information FAQ

€189.40

In stock - tax incl.

Key features according to our expert

Inner diameter: 20 mm
Connection type: Internal thread
Thread type: Metric fine
Sealing (bearing): Without seals
Maintenance free: Yes
Connection size: M20 x 1,5

Product description

These SKF rod ends have an injection moulded sliding layer of PTFE FRP between the housing and the inner ring. This sliding contact surface combination is maintenance-free. The male thread is available with a left- (prefix SAL) or right-hand thread.

Long service life
Maintenance-free
Relatively insensitive to contaminants
Low coefficient of friction
Simple and ready-to-mount

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 20 mm
Connection type: Internal thread
Thread type: Metric fine
Sealing (bearing): Without seals
Maintenance free: Yes
Connection size: M20 x 1,5
Basic static load rating: 50
Attachment feature, rod end shank: Right-hand female thread
Material, housing: Steel
Sliding contact surface combination: Steel/PTFE FRP
Housing length, total: 105
Maintenance: Maintenance-free
Thread designation: M 20x1.5
Outside diameter, housing eye: 51
Bore diameter, bearing inner ring: 20
Sealing: Without
Material, inner ring: Bearing steel
Width, bearing inner ring: 25
Width, housing eye: 18.5
Basic dynamic load rating: 31
Centre height, housing (from end of shank): 77

Brand SKF
01390082
EAN 7316577003874
Supplier number SKF SIKB 20 F

Frequently asked questions about this product

Answered by specialists

What thread type does this SKF rod end have?: It features a metric fine female thread sized at M20x1.5 (right-hand thread).
What is the bore diameter of the bearing?: The bore inner diameter of the bearing is 20 mm.
Does the SKF SIKB 20 F require regular lubrication?: No, this rod end is maintenance-free due to its PTFE FRP sliding contact surface and requires no relubrication.
Does this rod end include seals?: No, this standard model is designed without integrated seals.
What applications is the SKF SIKB 20 F designed for?: It is designed for linkage assemblies and mechanical connections handling heavy loads and oscillating movements.
