SKF

SKF SI 17 ES Rod head with female thread 17 mm, M 16

Recommended Retail Price €144.64
71.60 tax incl.
€59.17 excl. VAT (incl. all environmental contributions)
On stock, immediately available. we have 2 products in stock.
each

  • Delivery by DHL

Product description

These SKF rod ends contain a spherical plain bearing with a steel/steel sliding contact surface combination. The bearing requires maintenance and can be relubricated via a lubrication hole in the housing and via the shaft. The female thread is available with a left- (prefix SIL) or right-hand thread.

  • Suitable for heavy static, alternating or impact loads
  • Simple and ready-to-mount
  • Easy to relubricate
Key features according to our expert
  • Inner diameter: 17 mm
  • Connection type: Inner thread
  • Thread type: Metric
  • Seal (bearing): Without seal
  • Maintenance free: Nein
  • Connection size: M16
Specifications / All features
  • Brand: SKF
  • EAN: 7316577002914
  • Supplier number: SKF SI 17 ES
Inner diameter
17 mm
Connection type
Inner thread
Thread type
Metric
Seal (bearing)
Without seal
Maintenance free
Nein
Connection size
M16
Bore diameter, bearing inner ring
17
Attachment feature, rod end shank
Right-hand female thread
Material, housing
Steel
Sliding contact surface combination
Steel/steel, standard
Housing length, total
92
Maintenance
Relubrication required
Thread designation
M 16
Material, outer ring
Bearing steel
Outside diameter, housing eye
47
Sealing
Without
Basic static load rating
44
Material, inner ring
Bearing steel
Width, bearing inner ring
14
Width, housing eye
11.5
Basic dynamic load rating
21.2
Centre height, housing (from end of shank)
67
