SKF HMV 74E hydraulic nut M370x5

Supplier number: SKF HMV 74E | EAN 7316577014443
Recommended Retail Price €6,266.59
4,286.20 tax incl.
€3,542.31 excl. VAT (incl. all environmental contributions)
On order: delivered from 13/10/2026

  • Delivery by DHL


€4,286.20
tax incl.

Product information

Key features according to our expert

  • Outer diameter: 486 mm
  • Width: 57 mm
  • Thread size*: Tr370 x 5

Product description

Facilitates easy and quick application of the high drive-up forces required for mounting bearings on tapered seatings. The hydraulic nut can also be used for dismounting bearings mounted on either adapter or withdrawal sleeves.

  • Quick connection coupling can be fitted on the face or side of the nut
  • A spare set of piston seals and maintenance kit is included
  • Supplied with a quick connection coupling to fit the SKF hydraulic pumps
  • Equipped with eyebolts, two tommy bars and four mating holes on their front face

Documents

All Features

Outer diameter
486 mm
Width
57 mm
Thread size*
Tr370 x 5
Thread form
ISO 2901-1977 tolerance class 7H
Piston area
32800
Maximum piston displacement
16
Connecting thread
Tr 370x5
Piston outer diameter
466
Piston width
11
Piston inner diameter
372
Product weight
39
Model
Metric thread
Outside diameter
486
Maximum pressure
400
  • Brand SKF
  • EAN 7316577014443
  • Supplier number SKF HMV 74E
