Product description: Deep groove ball bearings are particularly versatile They are simple in design, not removable, suitable for high to very high speeds and are very robust in operation, requiring little maintenance Deep raceways and close contact between raceways and balls make deep groove ball bearings suitable not only for radial loads, but also for axial loads in both directions, even at high speeds
Key features according to our expert
Inner diameter: 110 mm
Width: 38 mm
Number of rows: 1
Seal (bearing): Without seal
Material (bearing seal): Not applicable
Radial clearance: C3
Material (bearing): Steel
Material (cage): Brass (solid)
Bore type: Cylindrical
High temperature: No
Outer diameter: 200 mm
Specifications / All features
Brand:
SKF
01014633
EAN:
7316571417936
Supplier number:
SKF 6222 M/C3VL0241
Inner diameter
110 mm
Width
38 mm
Number of rows
1
Seal (bearing)
Without seal
Material (bearing seal)
Not applicable
Radial clearance
C3
Material (bearing)
Steel
Material (cage)
Brass (solid)
Bore type
Cylindrical
High temperature
No
Outer diameter
200 mm
Matched arrangement
No
Tolerance class
Normal
Radial internal clearance
C3
Basic static load rating
118 kN
Material, bearing
Bearing steel
Relubrication feature
Without
Reference speed
6,700 r/min
Lubricant
None
Cage
Machined metal
Locating feature, bearing outer ring
None
Filling slots
Without
Coating
Insulation coating on outer ring
Sealing
Without
Limiting speed
6,300 r/min
Bore diameter
110 mm
Basic dynamic load rating
151 kN
Outside diameter
200 mm
