SKF

SKF 29328 E spherical roller bearing cylindrical 140 x 240 x 60 mm

Recommended Retail Price €4,147.24
2,053.20 tax incl.
€1,696.86 excl. VAT (incl. all environmental contributions)
On order: delivered from 30/05/2026
each

  • Delivery by DHL

Product description

Spherical roller thrust bearings accommodate very heavy axial and considerable radial loads. They have the highest load rating of all thrust bearings, enabling compact, high power density bearing arrangements. By combining two or more spherical roller thrust bearings, it is possible to create a bearing arrangement that is either self-aligning, allowing misalignment of the shaft, or very stiff.

  • High load carrying capacity
  • Can accommodate combined loads
  • Allow misalignment or create very stiff bearing arrangements
  • Long service life and low friction
  • Separable design
Key features according to our expert
  • Inner diameter: 140 mm
  • Outer diameter: 240 mm
  • Width: 60 mm
Specifications / All features
  • Brand: SKF
  • EAN: 7316576608957
  • Supplier number: SKF 29328 E
Inner diameter
140 mm
Outer diameter
240 mm
Width
60 mm
Cage
Sheet metal
Skf performance class
SKF Explorer
Reference speed
1500
Basic static load rating
2850
Tolerance class
Normal
Locating feature, housing washer
None
Limiting speed
2600
Basic dynamic load rating
980
Bore diameter
140
Height
60
Outside diameter
240
Bore type
Cylindrical
