What are the measuring range and resolution of this indicator?

The Mitutoyo 543-580 ID-B1005 features a 0-5 mm measuring range and a 0.01 mm resolution.

Is this indicator protected against dust and coolant?

Yes, the IP66 rating provides strong protection against dust ingress and coolant splashes or water jets.

What is the benefit of the built-in ABSOLUTE sensor?

The ABSOLUTE sensor retains the origin point, eliminating the need to reset zero every time you turn it on.

What plunger style does this ID-B indicator feature?

It features a back-plunger design with a top-mounted LCD display for convenient reading in tight spaces.

What is the stem diameter of this digital indicator?

The indicator has a standard 8 mm stem diameter for mounting on stands and inspection fixtures.

MITUTOYO 543-580 ID-B Digimatic dial indicator 5 mm, 0.01 mm

Name: MITUTOYO 543-580 ID-B Digimatic dial indicator 5 mm, 0.01 mm
Brand: MITUTOYO
SKU: 41012450
Price: 303.04 EUR
Availability: PreOrder

Supplier number: MITUTOYO 543-580 | EAN 4946368554228

303.04 tax incl.

€250.45 excl. VAT (incl. all environmental contributions)

On order: delivered from 14/10/2026

Delivery by DHL

✆ Talk to a specialist

Accurate inspection with the Mitutoyo indicator

Practical benefits

Precise readings on components: Featuring a 0.01 mm resolution and 5 mm range, you capture exact dimensional measurements effortlessly.
Resilient in harsh workshops: The IP66-rated housing ensures you can work reliably around splashing coolants, water, and shop floor dust.
Slim back plunger design: The compact back-spindle configuration helps you mount the device easily into tight multi-point inspection fixtures.

In a nutshell

The right choise for

With the Mitutoyo 543-580 ID-B1005 indicator, you perform precise dimensional inspections on workpieces and quality control fixtures. Featuring a 0.01 mm resolution and a 0-5 mm measuring range, the digital display delivers clear readings without parallax errors. Its compact back-plunger design and standard 8 mm stem allow seamless mounting in tight multi-point setups and confined machine spaces. The rugged IP66-rated housing protects internal electronics against workshop dust and splashing coolants. In addition, the integrated absolute sensor retains your origin point, eliminating the need to re-zero every time you power on.

Product information FAQ

€303.04

tax incl.

Key features according to our expert

Max. measuring value: 5 mm
Reading: 0,01 mm mm
Measuring range: 0-5 mm

Product description:

Model with limited installation dimensions that is highly resilient and robust.
The ABSOLUTE Digimatic dial indicator ID-B offers you the following features:
- It is a probe model with readout at the top.
- Slim model so very suitable for multiple measurement setups.
- The ABSOLUTE sensor means you do not need to set the original setting every time it is switched on, saves you time and effort.
- Excellent resistance to water and dust (IP66 protection class) allows use in machine conditions with splashing coolant.
- Display with switchable display direction for more flexibility in built-in applications.
- Perform GO/±NG assessment when setting upper and lower tolerances.

All Features

Max. measuring value: 5 mm
Reading: 0,01 mm mm
Measuring range: 0-5 mm

Brand MITUTOYO
41012450
EAN 4946368554228
Supplier number MITUTOYO 543-580

Frequently asked questions about this product

Answered by specialists

What are the measuring range and resolution of this indicator?: The Mitutoyo 543-580 ID-B1005 features a 0-5 mm measuring range and a 0.01 mm resolution.
Is this indicator protected against dust and coolant?: Yes, the IP66 rating provides strong protection against dust ingress and coolant splashes or water jets.
What is the benefit of the built-in ABSOLUTE sensor?: The ABSOLUTE sensor retains the origin point, eliminating the need to reset zero every time you turn it on.
What plunger style does this ID-B indicator feature?: It features a back-plunger design with a top-mounted LCD display for convenient reading in tight spaces.
What is the stem diameter of this digital indicator?: The indicator has a standard 8 mm stem diameter for mounting on stands and inspection fixtures.
