bahco_4544_10

BAHCO 4544-10 trigger heavy-duty galvanised with three arms 10 mm-100 mm 130 mm

BAHCO
Supplier number: BAHCO 4544-10 | EAN 7314151844042
Recommended Retail Price €134.35
71.20 tax incl.
€58.84 excl. VAT (incl. all environmental contributions)
On order: delivered from 07/10/2026

✆ Talk to a specialist


Product information
€71.20
tax incl.

Product information

Key features according to our expert

  • Max. width: 100 mm
  • Hydraulical: No
  • Number of hooks: 3
  • Max. height: 80 mm

Product description:

  • Extractor: 2 and 3 arm
  • 4544-1 - 4544-4 with 2 arms
  • 4544-10 - 4544-30 with 3 arms
  • Finish: Galvanised
  • Material: special steel
  • Solid extractor transmission and self-centring arms
  • 4544/B: Spare body
  • 4544-1/B for 4544-1
  • 4544-2/B for 4544-2
  • 4544-3/B for 4544-3
  • 4544-4/B for 4544-4
  • 4544-10/B for 4544-10
  • 4544-20/B for 4544-20
  • 4544-30/B for 4544-30
  • 4544K: Spare arm
  • 4544K110 for 4544-1 and 4544-10
  • 4544K220 for 4544-2 and 4544-20
  • 4544K330 for 4544-3 and 4544-30
  • 4544-4519/S: Spare spindle
  • 4544-110/S for 4544-1 and 4544-10
  • 4544-220/S for 4544-2 and 4544-20
  • 4519-1/S for 4544-3 and 4544-30
  • 4544-440/S for 4544-4

All Features

Max. width
100 mm
Hydraulical
No
Number of hooks
3
Max. height
80 mm
Screw dimension mm
M12x1.25x162 mm
Width mm (a)
10-100 mm
Width extractor mm
10-100 mm
Maximum loading capacity kn
25 kN
Extractor height mm
80 mm
Torque range nm
25 N·m
Maximum loading capacity to
2,5 to
Size hexagon mm
14 mm
Arm length mm
80 mm
Weight g
790 g
