SPIT

SPIT 057667 FIX Z XTREM breach anchor M8x130 for cracked and uncracked concrete

1.56 tax incl.
€1.29 excl. VAT (incl. all environmental contributions)
On order: delivered from 28/05/2026
each

The minimum purchase order quantity for the product is 50.

  • Delivery by DHL

Product description

  • Piercing anchor for cracked and non-cracked concrete and seismic applications
  • ETA-approved quality anchor for safety applications
  • No wood deformation thanks to extra-large ring according to DIN 440 / ISO 7094
  • Widely applicable XTREM anchor thanks to CE approval for use in cracked and non-cracked concrete
  • High load capacity thanks to special geometry and segment thickness
  • High allowable loads thanks to special geometry and thickness of segment
  • Large range that can be used in all seismic C1 and C2 areas
  • Geometry ensures easy placement and fast installation due to minimum number of rotations
  • Maximum flexibility in thanks to fully continuous screw act

Applications

  • Steel structures
  • Safety fences
  • Curtain wall
  • Purlin
  • Wooden panel
  • HVAC
  • Timber structures
Key features according to our expert
  • Thread dimension: M8
  • Overall length: 130 mm
  • Surface treatment (bolt): Zinc plated
Specifications / All features
  • Brand: SPIT
  • EAN: 3439510576670
  • Supplier number: SPIT 057667
Thread dimension
M8
Overall length
130 mm
Surface treatment (bolt)
Zinc plated
Treatment
Galvanised
Min. edge distance (mm)
50 mm
Product material
Carbon steel
Head type
Loose nut head
Min. anchor distance
50 mm
Anchor diameter
8.0 mm
Maximum trapping
70 mm
Tightening torque
20 N-m
Min. thickness of base material
100 mm
Minimum drilling depth
65 mm
Base material
Cracked concrete, Non-cracked concrete
Drill diameter
8.0 mm
Maximum installation depth
46 mm
Throughput diameter
9 mm
Anchor length
130 mm
Wire diameter
M8
Key size
13.0 mm
Anchor screw material
Steel
