SKF

SKF UCT 207/H take-up unit with plug-in ball bearing, locking with set screw and widened inner ring, cast iron, JIS

Recommended Retail Price €104.08
51.40 tax incl.
€42.48 excl. VAT (incl. all environmental contributions)
On order: delivered from 23/05/2026
each

  • Delivery by DHL

Product description

Take-up ball bearing units, consisting of an insert bearing based on a sealed deep groove ball bearing mounted in a grey cast iron housing. Typically mounted in take-up frames, the unit has an inner ring extended on both sides and is locked by tightening two set screws on the inner ring, which makes it easy to mount. Units with designation suffix /H feature a 120° angle of separation between the set screws that contributes to a higher stability and a better load balance.

  • Designed for an alternating rotation
  • Quick and easy to mount onto the shaft
  • Accommodate static initial misalignment
  • Long service life
  • Reduced noise and vibration levels
Key features according to our expert
  • Shaft diameter: 35 mm
  • Material (bearing): Steel
  • Material (bearing housing): Cast iron
Specifications / All features
  • Brand: SKF
  • EAN: 7316579751957
  • Supplier number: SKF UCT 207/H
Shaft diameter
35 mm
Material (bearing)
Steel
Material (bearing housing)
Cast iron
Basic static load rating
15.3
Material, housing
Cast iron
Grease fitting
With
Hexagonal key size for set screw
3
Note
Limiting speed with shaft tolerance h6
Application
For material handling applications
Housing type
Take-up
Bore type
Cylindrical
Material, bearing
Bearing steel
Sealing, bearing
Seal and flinger on both sides
Sealing type
Contact, standard
Rubber seating ring
Without
Lubricant
Grease
Retaining feature, inner ring
Set screws
Bearing width, total
42.9
Sealing, unit
Optional end cover
Limiting speed
4300
Relubrication hole
With
Housing overall width
37
Basic dynamic load rating
25.5
Coating
Without
Set screw
M6x0.75
