SKF

SKF UCPA 204/H upright ball bearing unit with short base, widened inner ring and locking with set screw, Japanese standards

Recommended Retail Price €62.46
30.80 tax incl.
€25.45 excl. VAT (incl. all environmental contributions)
On order: delivered from 22/05/2026
each

  • Delivery by DHL

Product description

Short base pillow (plummer) block ball bearing units consist of an insert bearing mounted in a cast iron housing. This variant has threaded holes for attachment bolts and is suitable for applications where the direction of rotation is constant or alternating. It has an inner ring extended on both sides and is locked onto the shaft by tightening two set screws on the inner ring, making it easy to mount. The units are compliant with Japanese Industrial Standards (JIS).

  • Optimized for applications where space is limited
  • Ready to mount
  • Lubricated and sealed bearing
  • Quick locking onto the shaft
  • Extended inner ring for minimized shaft misalignment
Key features according to our expert
  • Shaft diameter: 20 mm
  • Bore type: Cylindrical
  • Material (bearing housing): Cast iron
  • Material (bearing): Steel
Specifications / All features
  • Brand: SKF
  • EAN: 7316579751858
  • Supplier number: SKF UCPA 204/H
Shaft diameter
20 mm
Bore type
Cylindrical
Material (bearing housing)
Cast iron
Material (bearing)
Steel
Set screw
M6x0.75
Material, housing
Cast iron
Grease fitting
With
Centre height (pillow block)
30.2
Hexagonal key size for set screw
3
Number of bolt holes for fasteners
2
Application
For material handling applications
Housing type
Pillow block
Material, bearing
Bearing steel
Sealing, bearing
Seal and flinger on both sides
Sealing type
Contact, standard
Rubber seating ring
Without
Lubricant
Grease
Note
Limiting speed with shaft tolerance h6
Retaining feature, inner ring
Set screws
Basic static load rating
6.55
Basic dynamic load rating
12.7
Coating
Without
Housing overall width
34
Bearing width, total
31
Relubrication hole
With
Fastening bolt hole type
Threaded
Limiting speed
6500
Sealing, unit
Without
Centre distance between bolt holes
52
Attachment thread diameter
M10
