SKF PFD 47 steel sheet bearing housing with triangular flange for insert bearings 47 x 16 mm

Recommended Retail Price €15.13

7.40 tax incl.

€6.12 excl. VAT (incl. all environmental contributions)

SKF PFD 47 steel sheet bearing housing with triangular flange for insert bearings 47 x 16 mm

€7.40 Recommended Retail Price €15.13

On order: delivered from 28/05/2026

set

The minimum purchase order quantity for the product is 10.

Delivery by DHL

Product information
Additional info

Product description

Triangular flanged pressed steel housings for insert bearings are lightweight and made from cold-rolled steel, and are zinc-coated for corrosion protection. The housings are cost-effective and designed for simple applications with light loads. The two-part housing, which has no provision for relubrication, can be ordered separately from the insert bearing, making a large number of combinations possible.

Lightweight
Cost-effective
Flexible bearing and housing combinations
Simple to mount
Protection against corrosion

Key features according to our expert

Seat diameter: 47 mm
Shape (bearing housing): Triangle
Material (bearing housing): Sheet steel

Specifications / All features

Brand: SKF
01190649
EAN: 7316570778076
Supplier number: SKF PFD 47

Seat diameter: 47 mm
Shape (bearing housing): Triangle
Material (bearing housing): Sheet steel
Grease fitting: Without
Spherical seating diameter: 47
Housing type: Flanged
Flanged housing type: Triangular
Number of bolt holes for fasteners: 3
Pitch diameter of bolt holes of round and triangle flange type housing: 71.4
Relubrication hole: Without
Fastening bolt hole type: Plain
Coating: Zinc-coated
Material, housing: Pressed steel
