SKF PF 80 steel sheet bearing housing with round flange for insert bearings 80 x 20 mm

SKF
Supplier number: SKF PF 80 | EAN 7316571070995
Recommended Retail Price €32.59
15.95 tax incl.
€13.18 excl. VAT (incl. all environmental contributions)
On order: delivered from 10/10/2026
set

The minimum purchase order quantity for the product is 5.

  • Delivery by DHL
↓ Documents (1) ✆ Talk to a specialist


Product information
€15.95
tax incl.

Product information

Key features according to our expert

  • Seat diameter: 80 mm
  • Shape (bearing housing): Round
  • Material (bearing housing): Sheet steel

Product description

Round flanged pressed steel housings for insert bearings are lightweight and made from cold-rolled steel, and are zinc-coated for corrosion protection. The housings are cost-effective and designed for simple applications with light loads. The two-part housing, which has no provision for relubrication, can be ordered separately from the insert bearing, making a large number of combinations possible.

  • Lightweight
  • Cost-effective
  • Flexible bearing and housing combinations
  • Simple to mount
  • Protection against corrosion

Documents

⤓ Technical data sheet PDF

All Features

Seat diameter
80 mm
Shape (bearing housing)
Round
Material (bearing housing)
Sheet steel
Grease fitting
Without
Spherical seating diameter
80
Housing type
Flanged
Flanged housing type
Round
Number of bolt holes for fasteners
4
Pitch diameter of bolt holes of round and triangle flange type housing
119
Relubrication hole
Without
Fastening bolt hole type
Plain
Coating
Zinc-coated
Material, housing
Pressed steel
  • Brand SKF
  • EAN 7316571070995
  • Supplier number SKF PF 80
