SKF P 80 standing bearing housing steel plate 80 mm

Supplier number: SKF P 80 | EAN 7316576667404
Recommended Retail Price €31.04
15.20 tax incl.
€12.56 excl. VAT (incl. all environmental contributions)
On order: delivered from 21/10/2026

The minimum purchase order quantity for the product is 5.

  • Delivery by DHL


€15.20
tax incl.

Product information

Key features according to our expert

  • Seat diameter: 80 mm
  • Material (bearing housing): Sheet steel

Product description

Pillow (plummer) block pressed steel housings for insert bearings are lightweight and made from cold-rolled steel, and are zinc-coated for corrosion protection. The housings are cost-effective and designed for simple applications with light loads. The two-part housing, which has no provision for relubrication, can be ordered separately from the insert bearing, making a large number of combinations possible.

  • Lightweight
  • Cost-effective
  • Flexible bearing and housing combinations
  • Simple to mount
  • Protection against corrosion

Documents

All Features

Seat diameter
80 mm
Material (bearing housing)
Sheet steel
Grease fitting
Without
Centre height (pillow block)
43.6
Spherical seating diameter
80
Housing type
Pillow block
Number of bolt holes for fasteners
2
Centre distance between bolt holes
120
Fastening bolt hole type
Plain
Relubrication hole
Without
Housing overall width
43
Coating
Zinc-coated
Material, housing
Pressed steel
  • Brand SKF
  • EAN 7316576667404
  • Supplier number SKF P 80
