SKF MB 17 lock washer for lock nuts 85 x 119 mm

Supplier number: SKF MB 17 | EAN 7316571770215

4.83 tax incl.

€3.99 excl. VAT (incl. all environmental contributions)

On stock - immediately available

Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Dependable locking with MB 17

Practical benefits

Prevents accidental loosening: The internal tab engages the shaft keyway to ensure your lock nut remains firmly in place.
Fast and straightforward installation: You easily bend one of the outer tabs into the nut slot for an immediate positive lock.
Precise metric dimensions: Designed with an 85 mm bore and 119 mm outer diameter for an exact fit on shafts.

In a nutshell

The right choise for

With the Skf mb 17 lock washer, you securely lock km 17 series lock nuts onto shafts and adapter sleeves. Severe vibrations and rotational forces in industrial gearboxes and rotating machinery can cause threaded fasteners to work loose over time. This steel lock washer, featuring an 85 mm inside diameter and a 119 mm outside diameter, prevents accidental loosening effectively. The inner tab engages the shaft keyway, allowing you to easily bend an outer tab into a slot on the lock nut for an immediate positive lock. This maintains axial bearing position and helps you prevent costly unplanned machine downtime.

Product information FAQ

€4.83

In stock - tax incl.

Key features according to our expert

Inner diameter: 85 mm
Outer diameter: 119 mm

Product description

MB and MBL lock washers are locking devices, used to secure KM, KML and HM .. T lock nuts onto a shaft or adapter sleeve and prevent unintentional loosening. MB .. A is a stronger version of the MB washer. The lock washers engage a keyway in the shaft or adapter sleeve thread. They lock the nut in position when one of the washer tabs is bent into one of the slots in the outside diameter of the lock nut. A new lock washer should be used each time the corresponding lock nut is installed.

Simple, stable and reliable fastening element
Easy to install and remove
Used for KM, KML, and HM .. T lock nuts

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 85 mm
Outer diameter: 119 mm
Outside diameter: 119
Bore diameter: 85
Locking device: Lock washer

Brand SKF
01230642
EAN 7316571770215
Supplier number SKF MB 17

Frequently asked questions about this product

Answered by specialists

What is the SKF MB 17 lock washer used for?: It is used to positively secure a lock nut (such as KM 17) onto a shaft or sleeve, preventing unintentional loosening.
What are the dimensions of this lock washer?: The SKF MB 17 has an inside diameter of 85 mm, an outside diameter of 119 mm, and a thickness of 1.75 mm.
Which lock nuts are compatible with the SKF MB 17?: This lock washer is designed for use with metric SKF KM 17 series lock nuts.
How does the locking mechanism work?: The inner tab engages the shaft keyway, and one outer tab is bent into a slot on the lock nut circumference.
Can you reuse a lock washer after removal?: No, you should always replace the lock washer with a new one whenever the nut is reinstalled.
