What are the dimensions of this SKF lock washer?

The washer has an inside diameter of 80 mm, an outside diameter of 112 mm, and a thickness of 1.75 mm.

What is the SKF MB 16 lock washer used for?

It is used to lock compatible lock nuts (such as KM 16) on a shaft or sleeve to prevent accidental loosening.

How does this lock washer secure the nut in place?

The inner tab engages the shaft keyway, and an outer tab is bent into one of the slots on the lock nut.

Can a used lock washer be reused?

No, a new lock washer should be installed every time the lock nut is replaced or refitted to ensure safety.

SKF MB 16 lock washer for lock nuts 80 x 112 mm

Supplier number: SKF MB 16 | EAN 7316571770222

4.33 tax incl.

€3.58 excl. VAT (incl. all environmental contributions)

On stock - immediately available

Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Secure locking with Skf MB 16

Practical benefits

Prevents accidental loosening: You keep lock nuts firmly in place by bending an outer tab into the nut slot.
Quick and simple installation: The inner tab aligns smoothly with the shaft keyway for effortless mounting.
Durable steel construction: You ensure a stable and reliable mechanical hold for demanding bearing arrangements.

In a nutshell

The right choise for

With the Skf mb 16 lock washer, you reliably prevent the accidental loosening of lock nuts like the km 16 on a shaft or adapter sleeve. Its durable steel construction delivers a dependable mechanical hold for bearing arrangements under heavy loads, eliminating the need for threadlocking fluids. Installation is fast and simple: the inner tab slides directly into the shaft keyway, after which you bend an outer tab into the slot of the lock nut. Featuring an inside diameter of 80 mm and an outside diameter of 112 mm, this lock washer ensures stable axial locking in rotating equipment.

Product information FAQ

€4.33

In stock - tax incl.

Key features according to our expert

Inner diameter: 80 mm
Outer diameter: 112 mm

Product description

MB and MBL lock washers are locking devices, used to secure KM, KML and HM .. T lock nuts onto a shaft or adapter sleeve and prevent unintentional loosening. MB .. A is a stronger version of the MB washer. The lock washers engage a keyway in the shaft or adapter sleeve thread. They lock the nut in position when one of the washer tabs is bent into one of the slots in the outside diameter of the lock nut. A new lock washer should be used each time the corresponding lock nut is installed.

Simple, stable and reliable fastening element
Easy to install and remove
Used for KM, KML, and HM .. T lock nuts

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 80 mm
Outer diameter: 112 mm
Outer diameter: 112
Bore diameter: 80
Locking device: Lock washer

Brand SKF
01230641
EAN 7316571770222
Supplier number SKF MB 16

Frequently asked questions about this product

Answered by specialists

What are the dimensions of this SKF lock washer?: The washer has an inside diameter of 80 mm, an outside diameter of 112 mm, and a thickness of 1.75 mm.
What is the SKF MB 16 lock washer used for?: It is used to lock compatible lock nuts (such as KM 16) on a shaft or sleeve to prevent accidental loosening.
How does this lock washer secure the nut in place?: The inner tab engages the shaft keyway, and an outer tab is bent into one of the slots on the lock nut.
Can a used lock washer be reused?: No, a new lock washer should be installed every time the lock nut is replaced or refitted to ensure safety.
