SKF FYTJ 35 KF Y ball bearing unit with flange oval, d 30 mm, A 34 mm, J 130 mm

Show more features

Shaft diameter

30 mm

Split

No

Material (bearing housing)

Stainless steel

Material (bearing)

Steel

High temperature

No

Bore type

Tapered

Shape (bearing housing)

Oval

Lubricant

Grease

Bearing width, total

30.5 mm

Material, housing

Cast iron

Basic static load rating

15.3 kN

Number of bolt holes for fasteners

2

Sealing, bearing

Seal and flinger on both sides

Rubber seating ring

Without

Sealing type

Contact, standard

Centre distance between bolt holes

130 mm

Material, bearing

Bearing steel

Flanged housing type

Oval

Retaining feature, inner ring

Adapter sleeve

Limiting speed

5,300 r/min

Grease fitting

With

Sealing, unit

Without

Width, total

43.25 mm

Fastening bolt hole type

Plain

Relubrication hole

With

Housing overall width

34 mm

Basic dynamic load rating

25.5 kN

Coating

Without

Housing type

Flanged
