SKF FYTB 504 M bearing housing with oval flanges for insert bearing, cast iron

Supplier number: SKF FYTB 504 M | EAN 7316570578010

Recommended Retail Price €37.95

18.60 tax incl.

€15.37 excl. VAT (incl. all environmental contributions)

On stock - immediately available | we have 2 products in stock.

Delivery by DHL

↓ Documents (1) ✆ Talk to a specialist

Reliable housing support for insert bearings

Practical benefits

Durable cast iron build: The Skf FYTB 504 M grey cast iron construction gives you dependable strength in demanding operational environments.
Compact two-bolt mounting: The oval flange design allows you to easily attach the unit to machine frames and tight spaces.
Precise bearing fit: With a 47 mm spherical seating diameter, you ensure accurate alignment and secure seating for compatible insert bearings.

In a nutshell

The right choise for

With the Skf fytb 504 M flanged housing, you create a dependable and sturdy bearing arrangement for demanding operational environments. Built from robust grey cast iron, it reliably handles mechanical loads across machine frames, conveyor systems, and agricultural equipment. The compact oval two-bolt flange allows you to mount the unit easily and securely in tight spaces and on vertical walls. Featuring a precise 47 mm spherical seating diameter and a 90 mm hole center distance, it ensures your compatible Y-insert bearing is accurately aligned and firmly supported.

Product information FAQ

€18.60

In stock - tax incl.

Key features according to our expert

Seat diameter: 47 mm
Material (bearing housing): Cast iron
Shape (bearing housing): Oval

Product description

These oval flanged housings for insert bearings are made of grey cast iron and can be bolted with two bolts to a machine wall or frame. They have been developed for bearing arrangements that must operate reliably in difficult environments.

Resist high levels of contamination
Accommodate relatively heavy loads

Documents

⤓ Technical data sheet PDF

All Features

Seat diameter: 47 mm
Material (bearing housing): Cast iron
Shape (bearing housing): Oval
Fastening bolt hole type: Plain
Grease fitting: With
Spherical seating diameter: 47
Housing type: Flanged
Flanged housing type: Oval
Number of bolt holes for fasteners: 2
Centre distance between bolt holes: 90
Housing overall width: 29.5
Relubrication hole: With
Coating: Without
Material, housing: Cast iron

Brand SKF
01190845
EAN 7316570578010
Supplier number SKF FYTB 504 M

Frequently asked questions about this product

Answered by specialists

Is the insert bearing included with this housing?: No, this product includes only the cast iron housing. You select a compatible Y-bearing with a 47 mm outer diameter.
What is the spherical seating diameter of this housing?: This flanged housing has a spherical seating diameter of 47 mm.
What is the center distance between the bolt holes?: The center-to-center distance between the two mounting holes is 90 mm.
What material is the SKF FYTB 504 M made of?: The housing is made of durable grey cast iron, engineered for demanding industrial environments.
How is this oval flanged housing mounted?: It is bolted to a wall or frame using two bolts through the 11.5 mm mounting holes.
