SKF

SKF 22309 EK double-row tapered roller bearing 45 x 100 x 36 mm

Recommended Retail Price €332.21
164.40 tax incl.
€135.87 excl. VAT (incl. all environmental contributions)
On order: delivered from 30/05/2026
each

  • Delivery by DHL

Product description

Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.

  • Accommodate misalignment
  • High load carrying capacity
  • Relubrication features
  • Low friction and long service life
  • Increased wear resistance
Key features according to our expert
  • Inner diameter: 45 mm
  • Width: 36 mm
  • Number of rows: 2
  • Seal (bearing): Without seal
  • Material (bearing seal): Not applicable
  • Radial clearance: CN (Normal)
  • Material (cage): Brass (sheet)
  • Bore type: Tapered
  • Outer diameter: 100 mm
Specifications / All features
  • Brand: SKF
  • EAN: 7316571580760
  • Supplier number: SKF 22309 EK
Inner diameter
45 mm
Width
36 mm
Number of rows
2
Seal (bearing)
Without seal
Material (bearing seal)
Not applicable
Radial clearance
CN (Normal)
Material (cage)
Brass (sheet)
Bore type
Tapered
Outer diameter
100 mm
Reference speed
5300
Basic static load rating
183
Relubrication feature
With
Tolerance class for run-out
P5
Skf performance class
SKF Explorer
Lubricant
None
Cage
Sheet metal
Locating feature, bearing outer ring
Without
Radial internal clearance
CN
Basic dynamic load rating
190
Sealing
Without
Limiting speed
7000
Bore diameter
45
Outside diameter
100
Tolerance class for dimensions
Normal
