PFERD ZYAS 0313/3 ALLROUND carbide high-efficiency burr cylinder 3x13mm 3mm universal coarse - 21001061

Supplier number: PFERD 21001061 | EAN 4007220391303
20.22 tax incl.
€16.71 excl. VAT (incl. all environmental contributions)
On order: delivered from 16/10/2026

  • Delivery by DHL


€20.22
tax incl.

Product information

Key features according to our expert

  • Diameter: 3 mm
  • Shank size (milling cutter): 3 mm
  • Shank type: Cylindrical
  • Shape (burr cutter): Cylindrical with end toothing (B)
  • Cutting length: 13 mm

Product description

  • PFERD Tungsten carbide high-performance burr ALLROUND cylindrical ZYAS end cut dia. 03x13mm shank dia. 3mm universal coarse

Characteristics

  • With the innovative ALLROUND cut, PFERD has developed unique burrs for versatile use on key materials such as steel and cast steel, stainless steel (INOX), non-ferrous metals and cast iron
  • The ALLROUND cut offers all the benefits of the tried-and-tested 3 PLUS cut, but its stock removal rate is up to 30 % higher for steel
  • It enables comfortable working with reduced vibration and less noise
  • The ALLROUND cut also helps users save considerable time when working, thus making it an economically efficient option
  • Cylindrical burr according to DIN 8032 with circumferential and end cut

Advantages:

  • Significantly better stock removal rate than burrs with a conventional cross cut.
  • Saves time and money thanks to its very high stock removal rate on key materials.
  • Comfortable working thanks to reduced vibration and less noise.
  • The highly accurate concentricity enables impactfree working without creating chatter marks. This considerably reduces wear on the tool and tool drive.

All Features

Diameter
3 mm
Shank size (milling cutter)
3 mm
Shank type
Cylindrical
Shape (burr cutter)
Cylindrical with end toothing (B)
Cutting length
13 mm
Rpm up to, hardened refined steels above 1,200 n/mm²
48000
Rpm up to, hard non-ferrous metals
64000
Rpm of, stainless and acid-resistant steels
48000
Rpm of, soft non-ferrous metals
48000
Rpm of, hard non-ferrous metals
48000
Rpm to, grey cast iron, white cast iron
95000
Rpm of, steels up to 1,200 n/mm²
48000
Rpm van, grey cast iron, white cast iron
48000
Gearing
ALLROUND
Rpm up to, steels up to 1,200 n/mm²
80000
Rpm of, hardened refined steels above 1,200 n/mm²
27000
Processing tasks
Obtaining cut-outs
Workable materials
Annealed cast iron
Length, toothed
13
ø shaft metric
3
  • Brand PFERD
  • EAN 4007220391303
  • Supplier number PFERD 21001061
