INGERSOLL RAND 2146Q1MAX pneumatic impact spanner square 3/4" 2712Nm

Name: INGERSOLL RAND 2146Q1MAX pneumatic impact spanner square 3/4" 2712Nm
Brand: INGERSOLL RAND
SKU: 03212118
Price: 581.2 EUR
Availability: PreOrder

Supplier number: INGERSOLL RAND 2146Q1MAX | EAN 0663023164588

581.20 tax incl.

€480.33 excl. VAT (incl. all environmental contributions)

On order: delivered from 30/09/2026

Delivery by DHL

✆ Talk to a specialist

Ingersoll Rand pneumatic impact wrench

Practical benefits

Extreme nut busting torque: With a breakaway torque of 2712 Nm, you effortlessly break free stubborn and seized fasteners.
Easy single handed operation: You change forward and reverse direction smoothly with one hand while feathering the trigger for precise speed.
Rugged twin hammer mechanism: The durable steel hammer case protects the internal components against drops and harsh workshop use.

In a nutshell

The right choise for

With the Ingersoll Rand 2146Q1MAX pneumatic impact wrench, you tackle heavy-duty assembly and maintenance on commercial vehicles or agricultural machinery with total confidence. Delivering a maximum breakaway torque of 2712 Nm, it effortlessly breaks free stubborn and seized fasteners. Offering a maximum tightening torque of 1763 Nm alongside a speed of 5500 rpm, you complete tough bolting jobs quickly and accurately. The rugged steel hammer case reliably protects the twin hammer mechanism against demanding workshop conditions. You can easily operate forward and reverse with one hand, while the 3/4" square drive and 3/8" air inlet connect seamlessly into your pneumatic setup.

Product information FAQ

€581.20

tax incl.

Key features according to our expert

Max. tightening torque: 1763 Nm
Tool holder size: 3/4"
Tool holder type: External square
Connection size (air): 3/8"
Speed: 5500 rpm
Max. breakeway torque: 2712 Nm

Product description

2700 Nm breakaway torque and 1970 Nm tightening torque in a compact impact spanner weighing only 3.5 kg
Innovative pressure gauge improves productivity and extends service life
Ability to quickly set optimum power settings increases productivity and speed
6-lobe motor delivers extra power
Cold-forged double hammer mechanism and motor deliver more torque, durability and efficiency
Optimised airflow for maximum performance when using this pneumatic impact wrench
Designed to withstand heavy use in harsh environments: steel hammer housing withstands drops
Hard anodised end plate for improved durability
Improved ergonomic comfort with a unit compact enough to access tight spaces
Quiet Technology reduces tool noise, saving your ears without compromising on power
Forward/reverse one-handed operation and featherweight trigger ensure maximum control
Easier access to the grease nipple for faster maintenance and less downtime
Optimised for the vehicle repair industry, body shops, general industrial use, MRO (Maintenance, Repair and Overhaul), railways, heavy machinery, oil and gas, shipbuilding and construction

All Features

Max. tightening torque: 1763 Nm
Tool holder size: 3/4"
Tool holder type: External square
Connection size (air): 3/8"
Speed: 5500 rpm
Max. breakeway torque: 2712 Nm
Anvil size (in): 3/4"
Max. speed ( min-1): 5500
Vibration (m/s²): 8.4
Breakaway torque max (nm): 2712
Max. release torque (nm): 1966
Stroke frequency (1 min): 1075
Forward/fast torque (nm): 1763
Sound pressure level (db (a)): 88.8 / 99.8
Air consumption (l/min): 396
Length (mm): 216
Connection wire: 1/2" NPT
Weight (kg): 3.54
Working pressure (bar): 6.2
Height (mm): 208
Width (mm): 89
Special features: Quiet, Air Pressure Gauge, Cold Forged Twin Hammers, Hard Anodized Wear Plates

Brand INGERSOLL RAND
03212118
EAN 0663023164588
Supplier number INGERSOLL RAND 2146Q1MAX

Frequently asked questions about this product

Answered by specialists

What is the maximum breakaway torque of this impact wrench?: It delivers a maximum breakaway torque of 2712 Nm to loosen heavily seized fasteners.
What are the drive size and air inlet specifications?: The impact wrench features a 3/4" external square drive and a 3/8" compressed air inlet.
What is the maximum tightening torque?: The maximum tightening torque is 1763 Nm with a free speed of 5500 rpm.
Which applications is the Ingersoll Rand 2146Q1MAX suitable for?: It is engineered for heavy industrial maintenance, commercial vehicle repair, agricultural machinery, and heavy assembly.
Which sockets are compatible with this tool?: All standard impact sockets with a 3/4" square drive fit directly onto the anvil.
