HI-FORCE HSS54 hydraulic single-acting multi-purpose cylinder, 4.5 tonnes, stroke length 100 mm

HI-FORCE
Supplier number: HI-FORCE HSS54 | EAN 5056388008829
629.20 tax incl.
€520.00 excl. VAT (incl. all environmental contributions)
On order: delivered from 02/10/2026

  • Delivery by DHL
  • Manual in your language included
↓ Documents (2) ✆ Talk to a specialist


Product information
€629.20
tax incl.

Product information

Key features according to our expert

  • Diameter: 38 mm
  • Stroke length: 100 mm
  • Max. capacity: 4,5 t
  • Height: 182 mm

Product description

  • Single-acting, spring return
  • Nitrocarbonised plunger for corrosion resistance
  • Bearing surfaces with minimal friction
  • Anti-extrusion seals for improved high-pressure performance
  • Bearing thread suitable for full load
  • Slotted saddles fitted as standard on all models
  • Capacity: 4.5 tonnes
  • Stroke length: 100 mm
  • Oil capacity: 64 cm³
  • Construction height: 182 mm
  • Cylinder diameter: 38 mm
  • Piston diameter: 24 mm
  • Weight: 1.5 kg
  • Max. working pressure: 700 bar
  • Complete with quick-release coupling

Documents

⤓ Parts list PDF ⤓ Instruction manual PDF

All Features

Diameter
38 mm
Stroke length
100 mm
Max. capacity
4,5 t
Height
182 mm
  • Brand HI-FORCE
  • EAN 5056388008829
  • Supplier number HI-FORCE HSS54
