What is the torque range of this torque wrench?

The torque range of the Gedore TF-SE25 is 5 to 25 Nm (3.7 to 18 lbf·ft) for precise screw tightening.

Which drive fitting does the Gedore TF-SE25 have?

This torque wrench features a 9x12 mm rectangular cavity designed for compatible insert tools.

Can it be used for clockwise and counter-clockwise tightening?

Yes, controlled bi-directional tightening is achieved simply by turning over the insert tool.

What is the accuracy of this torque wrench?

It is calibrated to a maximum deviation of +/- 3% in accordance with DIN EN ISO 6789-2:2017 Type II Class A.

Is this tool VDE certified?

No, this model is not VDE certified and must not be used on live electrical circuits.

GEDORE TF-SE25 Torcofix SE 9x12 torque spanner, 5-25 Nm - 3288196

Name: GEDORE TF-SE25 Torcofix SE 9x12 torque spanner, 5-25 Nm - 3288196
Brand: GEDORE
SKU: 08088317
Price: 143.8 EUR
Availability: PreOrder

Supplier number: GEDORE 3288196 | EAN 4010886965535

Recommended Retail Price €147.14

143.80 tax incl.

€118.84 excl. VAT (incl. all environmental contributions)

On order: delivered from 15/10/2026

Delivery by DHL

✆ Talk to a specialist

Accurate tightening with Gedore precision

Practical benefits

High torque setting accuracy: You secure critical fasteners from 5 to 25 Nm with a tight +/-3 % deviation for dependable mechanical assemblies.
Clear tactile release signal: The integrated short-path mechanism alerts you instantly with a distinct click when reaching your desired torque setting.
Versatile rectangular drive holder: Utilizing the 9x12 mm cavity, you easily attach suitable insert tools for controlled clockwise and counterclockwise operations.

In a nutshell

The right choise for

With the Gedore TF-SE25 Torcofix se torque wrench, you gain full control over every delicate mechanical assembly. Whether working on sensitive bicycle parts, automotive maintenance, or precision engineering, the 5 to 25 Nm range ensures fasteners are tightened to exact specifications. a tight +/-3 % accuracy combined with a distinct tactile and audible release mechanism protects delicate materials and prevents overtightening or thread damage. Thanks to the versatile 9x12 mm rectangular cavity, you can quickly mount interchangeable insert tools for controlled clockwise and counterclockwise tightening. This gives you the speed, reliability, and confidence needed for professional results on every job.

Product information FAQ

€143.80

tax incl.

Key features according to our expert

Max. tightening torque: 25 Nm
Drive profile size: 9 x 12 mm
Material ( torque tool): Aluminium alloy
VDE approved: No
With safety colour code 1000V: Not applicable
Display: Analogue
Overall length: 261,5 mm
Min. tightening torque: 5 Nm

Product description

Application Controlled screw tightening in the range 5 - 25 Nm / 3.7 - 18 lbf-ft
Adjustable, audible and tactile switch-off, robust torque spanner with rectangular SE take-up
Design Classified according to DIN EN ISO 6789-22017 Type II Class A, calibrated with a maximum permissible deviation of +/- 3% and thus more accurate than the +/- 4% required by the standard
Including traceable test certificate (DIN EN ISO 6789-22017)
For controlled clockwise and anticlockwise tightening (reversing insert for change of direction)
Rectangular holder 9x12 mm including ejector tool
Robust, matt powder-coated steel pipe construction, with galvanised ratchet and high-quality plastic parts
New ergonomic handle, shaped according to the natural grip position of the hand
Clearly identifiable, hand-feeling centring and calibration aid in the middle of the handle
Double scale Nm / lbf-ft with vernier (Nm), enlarged viewing window protects against dirt and damage
With vernier scale for Nm main scale for setting intermediate scale values
Lbf-ft setting via main scale only
Vertical arrangement of scale, thus suitable for left- and right-handed users
Setting mark directly above scale, prevents reading errors (parallax error)
Unit marking integrated in the scale and also protected from dirt by viewing window
Precise turn-off mechanism generates a clear tactile and audible signal when the set tightening value is reached
Includes roll-off safety device, prevents rolling away when the spanner is put down

All Features

Max. tightening torque: 25 Nm
Drive profile size: 9 x 12 mm
Material ( torque tool): Aluminium alloy
Vde approved: No
With safety colour code 1000v: Not applicable
Display: Analogue
Overall length: 261,5 mm
Min. tightening torque: 5 Nm
Test certificate: DIN EN ISO 6789-2:2017
Fixed setting: No
Drive type/drive: Rectangle recording
Tightening torque (min.) [lbf-ft]: 3.7 lbf-ft
Pitch size [metric]: 17.5 mm
Tightening direction: Left and right
Scale division [nm]: 1 Nm
Precision +/-: +/- 3 %
Storage/contents: Plastic box
Vernier nm: 0.1 Nm
Overall length [mm]: 261.5 mm
Torque (min.) [nm].: 5 Nm
Torque (max.) [nm].: 25 Nm
Drive intake, rectangular...: 9 x 12 mm
Turn-off mechanism: Short road clearance
Tightening range (min/max) [lbf-ft].: 3.7 lbf-ft - 18 lbf-ft
Calibration length: 261.5 mm
Tightening torque (max) [lbf-ft]: 18 lbf-ft
Scale division [lbf-ft]: 1 lbf-ft
Target groups: AutomotiveIndustry Construction and commercial vehicles Military Energy Mechanical Engineering Utilities Service Agriculture Oil and gas
Torque range (min./max.) [nm].: 5 Nm - 25 Nm
Scope: MountingSeries assembly Production Maintenance and repair
Material: Tubular steel construction with high-quality plastic parts
Scale: 1

Brand GEDORE
08088317
EAN 4010886965535
Supplier number GEDORE 3288196

Frequently asked questions about this product

Answered by specialists

What is the torque range of this torque wrench?: The torque range of the Gedore TF-SE25 is 5 to 25 Nm (3.7 to 18 lbf·ft) for precise screw tightening.
Which drive fitting does the Gedore TF-SE25 have?: This torque wrench features a 9x12 mm rectangular cavity designed for compatible insert tools.
Can it be used for clockwise and counter-clockwise tightening?: Yes, controlled bi-directional tightening is achieved simply by turning over the insert tool.
What is the accuracy of this torque wrench?: It is calibrated to a maximum deviation of +/- 3% in accordance with DIN EN ISO 6789-2:2017 Type II Class A.
Is this tool VDE certified?: No, this model is not VDE certified and must not be used on live electrical circuits.
