GEDORE 1.10/4 universal puller 320x260 mm - 1731882

Name: GEDORE 1.10/4 universal puller 320x260 mm - 1731882
Brand: GEDORE
SKU: 01041074
Price: 215.6 EUR
Availability: PreOrder

Supplier number: GEDORE 1731882 | EAN 4036976112771

Recommended Retail Price €358.26

215.60 tax incl.

€178.18 excl. VAT (incl. all environmental contributions)

On order: delivered from 06/10/2026

Delivery by DHL

✆ Talk to a specialist

High pulling force for heavy mechanical components

Practical benefits

Reliable Gedore engineering: You effortlessly remove stubborn bearings, pulleys, and gear wheels with a heavy-duty frame designed for demanding mechanical tasks.
Generous reach and spread: A 320 mm clamping width and 260 mm depth give you the capacity to handle large machinery parts with ease.
Secure self-gripping legs: The reversible arms automatically tighten their grip under load, ensuring you maintain a stable and slip-free hold throughout extraction.

In a nutshell

The right choise for

With the Gedore 1.10/4, you effortlessly remove stubborn bearings, pulleys, and gear wheels without damaging surrounding shafts or machine components. This heavy-duty 2-arm mechanical puller is made from robust tool steel and delivers a maximum pull capacity of up to 8.0 t, eliminating the need for destructive hammer blows or torch heating. Featuring a generous clamping width of 320 mm and a reach of 260 mm, it easily handles large press-fit components. The reversible double-ended legs offer wide and narrow gripping ends that automatically tighten under load, ensuring a stable, safe, and slip-free extraction in any workshop or maintenance setting.

Product information FAQ

€215.60

tax incl.

Key features according to our expert

Max. width: 320 mm
Puller type: Universel puller
Hydraulical: No
Number of hooks: 2
Max. height: 260 mm

Product description

Proven, powerful design for pulling loose discs, wheels, ball bearings, etc.
The double-sided use of wide or narrow hook ends pulls itself tight
The wide hook ends of pullers No. 1.10/2, /3, /4 and /5 are fitted with 8 mm slots, so that discs or gears can also be pulled out using 8 mm screws

All Features

Max. width: 320 mm
Puller type: Universel puller
Hydraulical: No
Number of hooks: 2
Max. height: 260 mm
Towing force (max.) [t]: 8
Clamping bracket available: No
Hook foot thickness at end e1 [mm]: 6.5 mm
Hook foot depth usable d2 [mm]: 27 mm
Suitable for use with a hydraulic spindle: No
Hydraulic spindle optional: 1.06/HSP1
Screws included: No
Hook foot width on the gripping surface c1 [mm]: 27 mm
Number of arms: 2
Reversible arms available: No
Double-sided hooks: No
Hook brake available: No
Drive hexagonal width: 22 mm
Spindle thread size: G 1/2 x 350
Crochet foot width: 32 mm
Span when pulled externally (max) [mm].: 320 mm
Spindle-slide protection: No
Automatic pressing: No
Clamping depth usable b [mm]: 260 mm

Brand GEDORE
01041074
EAN 4036976112771
Supplier number GEDORE 1731882

Frequently asked questions about this product

Answered by specialists

What is the maximum capacity of this puller?: The puller has a maximum clamping width of 320 mm and a reach of 260 mm.
Is this puller hydraulically operated?: No, this model operates mechanically via a threaded spindle and is not hydraulic.
What is this universal puller used for?: This 2-arm puller is designed for pulling off bearings, pulleys, wheels, and gears.
Are the puller legs reversible?: Yes, the double-ended legs offer both wide and narrow gripping ends for versatile use.
What is the maximum load capacity of this model?: This model has a maximum pull capacity of 8.0 t.
