Product description
- Combination of 2 functions: cutting and stripping.
- Play adjustment mechanism, devised for effortless stripping without jerking.
- Stripping capacity: 0.02 to 10 mm² (AWG: 32 - 8).
- Stripping length can be adjusted between 3 and 18 mm.
- With built-in cutting function
- Cutting up to: 1.5 mm² single-wire cable
- Cutting up to: 10 mm² multiwire cable.
- Ergonomic housing made of fibreglass-reinforced nylon
- 793207: Spare claw
- 793210: Set of 2 rubber ends for the jaw.
- PB version: delivered in commercial packaging
Key features according to our expert
-
For min. cable cross-section: 0,02 mm²
-
With automatic stripping function: Yes
-
With cutting function: Yes
-
With crimping function: No
-
Adjustment type: Automatic
-
VDE approved: No
-
With safety colour code 1000V: Not applicable
-
Supplier warranty: FACOM - Lifetime (E)
-
For max. cable cross-section: 10 mm²
Specifications / All features
- For min. cable cross-section
- 0,02 mm²
- With automatic stripping function
- Yes
- With cutting function
- Yes
- With crimping function
- No
- Adjustment type
- Automatic
- Vde approved
- No
- With safety colour code 1000v
- Not applicable
- Supplier warranty
- FACOM - Lifetime (E)
- For max. cable cross-section
- 10 mm²
- Strip range awg/maximum value
- 32
- Adjustable core depth
- No
- Self-adjusting
- Yes
- Strip cross-sectional area (mm²)/minimum value
- 0.02
- Insulated 1000 v
- No
- Vde tested
- No
- Strip cross-sectional area (mm²)/maximum value
- 10
- Esd tested (electrostatic discharge)
- No
- Circular cut
- No
- With stopper protection
- No
- Strip range awg/minimum value
- 8
- Strip length adjustable
- Yes
- Weight (g)
- 136
- Spiral cut
- No
- Longcut
- Yes
- Handle version
- 2-component
- Insulated
- No
- Handle
- Plastic sleeve
- With thread cutter
- Yes
