bahco_247_50

BAHCO 247-50 socket spanner with rectangular connection 24x32 mm, 50 mm

Supplier number: BAHCO 247-50 | EAN 7314150367153
Recommended Retail Price €498.28
303.95 tax incl.
€251.20 excl. VAT (incl. all environmental contributions)
On order: delivered from 10/10/2026

  • Delivery by DHL


€303.95
tax incl.

Product information

Key features according to our expert

  • Width across flats: 50 mm
  • Connection size (wrench): 24 x 32 mm
  • Connection type (wrench): External rectangle

Product description:

  • Insert spanner, rectangular socket 24x32 mm, 50 mm

Features:

  • The insert is secured to the torque spanner with a spring-loaded retractable pin
  • The range varies from 9 x 12 to 27 x 36 holders, from 7 to 90 mm openings and from 9 to 3000Nm
  • For sizes with * in the torque length, the torque setting must be calculated
  • Suitable for 7465, 74W9, 74W14, 74P9, 74P14, IZO-D, TAW9, TAW14, TAW24, TAWM9, TAWM14 and TAWM24 spanners

All Features

Width across flats
50 mm
Connection size (wrench)
24 x 32 mm
Connection type (wrench)
External rectangle
Diameter inch
50 in
Weight g
1270 g
Working length mm (l)
50 mm
Length of square mm
32 mm
Head width mm (d)
104 mm
Width mm (b)
100 mm
Total length mm (a)
117 mm
Length and width of square mm
24x32 mm
Height mm (h)
25 mm
Weight kg
1.270 kg
Max torque range nm
1200 N·m
Length mm
*55 mm
Width of square mm
24 mm
Diameter mm
50 mm
  • Brand BAHCO
  • EAN 7314150367153
  • Supplier number BAHCO 247-50
