SKF HMV 36E hydraulische moer M180x3

Artikelnummer leverancier: SKF HMV 36E | EAN 7316577014276
Adviesprijs € 2.624,49
 1.794,95 incl. BTW
€ 1.483,43 excl. BTW (incl. alle milieubijdrages)
Op bestelling: bezorgd vanaf 13/10/2026
stuk

  • Bezorging door DHL
  • Handleiding in jouw taal inbegrepen


€ 1.794,95
incl. BTW

Productinformatie

Belangrijkste eigenschappen volgens onze expert

  • Buitendiameter: 256 mm
  • Breedte: 41 mm
  • Maat schroefdraad*: M180 x 3

Productomschrijving

Facilitates easy and quick application of the high drive-up forces required for mounting bearings on tapered seatings. The hydraulic nut can also be used for dismounting bearings mounted on either adapter or withdrawal sleeves.

  • Quick connection coupling can be fitted on the face or side of the nut
  • A spare set of piston seals and maintenance kit is included
  • Supplied with a quick connection coupling to fit the SKF hydraulic pumps
  • Equipped with eyebolts, two tommy bars and four mating holes on their front face

Documenten

Alle eigenschappen

Buitendiameter
256 mm
Breedte
41 mm
Maat schroefdraad*
M180 x 3
Vorm schroefdraad
ISO 965/111-1980 tolerance class 6H
Zuigeroppervlak
10300
Maximale zuigerverplaatsing
6
Schroefdraad aansluiting
M 180x3
Buitendiameter zuiger
247
Zuigerbreedte
7
Binnendiameter zuiger
180.5
Productgewicht
9.15
Type
Metric thread
Maximale druk
800
  • Merk SKF
  • EAN 7316577014276
  • Artikelnummer leverancier SKF HMV 36E
