skf_hmv69e

SKF HMV 69E écrou hydraulique M345x5

5 314,66  TTC
4 428,88 € HT (éco-contributions incluses)
En commande : livraison à partir du 28/05/2026

  • Commandé avant 20h - livré à partir du 28/05/2026
  • Livraison par DHL
  • Manuel d'utilisation dans votre langue inclus

Description du produit

Facilitates easy and quick application of the high drive-up forces required for mounting bearings on tapered seatings. The hydraulic nut can also be used for dismounting bearings mounted on either adapter or withdrawal sleeves.

  • Quick connection coupling can be fitted on the face or side of the nut
  • A spare set of piston seals and maintenance kit is included
  • Supplied with a quick connection coupling to fit the SKF hydraulic pumps
  • Equipped with eyebolts, two tommy bars and four mating holes on their front face
Principales caractéristiques selon notre expert
  • Diamètre extérieur: 456 mm
  • Largeur: 54 mm
  • Dimension nominale du filetage*: Tr345 x 5
Spécifications / Toutes les caractéristiques
  • Marque: SKF
  • EAN: 7316577106612
  • Numéro d'article du fournisseur: SKF HMV 69E
Diamètre extérieur
456 mm
Largeur
54 mm
Dimension nominale du filetage*
Tr345 x 5
Filetage
ISO 2901-1977 tolerance class 7H
Zone du piston
29400
Déplacement maximal du piston
14
Filetage de raccordement
Tr 345x5
Diamètre extérieur de piston
436
Largeur de piston
10
Diamètre intérieur de piston
347
Poids du produit
32.5
Type
Metric thread
Pression maximum
40
